Custom OS2 MTP®-12 APC to 6x LC UPC Uniboot Trunk Cable, 12-Fiber Single-Mode
-
Long-Reach & High-Density: The ultimate single-mode backbone solution, effortlessly breaking out a 10G/40G/100G MTP trunk into 6 discrete LC duplex connections over long distances.
-
50% Space Reduction: Advanced LC Uniboot technology houses two single-mode fibers in one slim round cable, drastically cutting rack congestion and optimizing thermal airflow.
-
Precision APC Polish: Features elite MTP® APC (Angled Physical Contact) connectors to strictly minimize back reflection (RL ≥ 60dB), a critical requirement for pristine single-mode signaling.
-
Ruggedized Backbone Ready: Engineered for rigorous facility routing. Available with customized lengths, precise breakout staggers, and optional pulling eyes for safe conduit installation.
-
Factory Direct Agility: Manufactured in our advanced 400-500 employee facility. We guarantee 100% 3D interferometer testing, massive production scalability, and rapid global fulfillment.
Product Overview
The Wolontek Custom OS2 MTP-12 to LC Uniboot Trunk Cable is an elite enterprise solution designed for the most demanding, space-constrained single-mode network architectures. As data centers scale their 10G, 40G, and 100G backbones across vast facilities, traditional LC zipcord cables create dense "spaghetti" loops that obstruct essential cooling systems. This advanced trunk cable eradicates that congestion by utilizing LC Uniboot connectors, which consolidate the duplex single-mode fibers into a single 2.0mm or 3.0mm jacket—reducing LC-end cable bulk by exactly 50%.
Constructed with premium 9/125μm OS2 single-mode fiber, this trunk assembly supports immense bandwidth over kilometers of reach. To ensure flawless optical performance, the 12-fiber MTP connector utilizes an APC (Angled) polish to prevent signal degradation caused by back reflection. Fully customized to your data center's exact layout, this plug-and-play assembly eliminates the excessive labor and unreliability of field terminations.
Key Features
-
Uniboot Airflow Optimization: Maximizes patch panel real estate and significantly improves the cooling efficiency of your critical network hardware.
-
100% Factory Terminated & Tested: Every trunk cable is meticulously assembled and rigorously tested for insertion loss and return loss, ensuring immediate carrier-grade reliability.
-
Bend-Insensitive OS2 Fiber: Utilizes G.657.A1 bend-insensitive single-mode fiber, preventing optical attenuation even when routed through tight, 10mm radius pathways.
-
Optional Pulling Eye: For long-distance routing through conduits or raised floors, a customized pulling eye can be factory-installed to protect the delicate MTP APC and LC UPC connectors from tension damage.
-
Standard Yellow Jacket: Encased in an industry-standard yellow jacket for immediate visual identification of single-mode routes within mixed-cabling environments.
Technical Specifications
| Specification | Details |
| Connector A | 1x MTP®-12 (Female/Male Customizable) - APC Polish |
| Connector B | 6x LC UPC Duplex - Uniboot Design |
| Fiber Count | 12-Fiber (Base-12) |
| Fiber Category | OS2 Single-mode 9/125μm |
| Insertion Loss (MTP) | ≤ 0.35dB (Low Loss) |
| Return Loss (MTP APC) | ≥ 60dB |
| Insertion Loss (LC UPC) | ≤ 0.20dB |
| Cable Diameter (LC End) | 2.0mm / 3.0mm (Single Round Cable) |
| Wavelength | 1310nm / 1550nm |
| Jacket Color | Yellow (LSZH / OFNP / OFNR options) |
Application Scenarios
This single-mode Uniboot trunk cable is indispensable for large-scale, high-density environments:
-
Data Center Interconnect (DCI): Breaking out long-haul single-mode backbones into manageable LC connections across expansive data halls.
-
Ultra-Dense Telecom Rooms: Upgrading legacy single-mode patching zones where physical rack space and conduit capacity are entirely exhausted.
-
Carrier & ISP Networks: Providing reliable, low-loss distribution for high-speed single-mode optical transceivers.
