Custom MTP/MPO Breakout & Fanout Cables
Transition from 40G/100G/400G high-density backbones to standard LC/SC/ST equipment with Wolontek’s precision-engineered MPO breakout cables & Fanout Cables. As a premier direct factory, we provide 100% customizable fanout assemblies with ultra-low insertion loss and bespoke routing configurations for mission-critical data centers.
MTP/MPO to LC Harness Cables (Switch-to-Server)
Cisco Compatible MPO to LC Breakout & Fanout Cables Reduce rack congestion by up to 50% with our ultra-slim MTP fanout cables. Our Cisco compatible MPO to LC breakout cables are rigorously 3D-tested to guarantee seamless integration with Cisco, Arista, and Juniper hardware. Benefit from our OEM customization service, offering low-insertion loss (Elite Grade 0.35dB) and various jacket ratings (OFNP/LSZH) tailored to your specific switch-to-server backbone links.
💡 Factory Direct Customization: Need specific lengths, staggered legs, or distinct polarities? All cables are 100% OEM configurable with premium US Conec MTP® or standard MPO connectors. Scroll down to view all bespoke options or contact us directly!
100% 3D Tested & OEM Configurable:
Every assembly passes strict 3D end-face geometry and IL/RL testing.
Custom OM4 MTP-8 to 4x LC UPC Harness, 8-Fiber, Type B
Optimize your 40G/100G enterprise networks with this premium OM4 mpo breakout cable. Designed to directly split a 40G QSFP+ or 100G QSFP28 port into four LC duplex connections. As a direct factory, we offer these high-density fiber patch cables in bespoke lengths with zero wasted fibers and guaranteed low insertion loss.
Custom OS2 MTP-8 APC to 4x LC UPC Harness, 8-Fiber, Type B
Seamlessly transition your 100G PSM4 to 4x 25G LR routing with our singlemode OS2 mpo to lc breakout cable. Factory-terminated with APC polish to minimize back reflection. Source your mpo fiber optic cable solutions directly from our WolonFiber factory for long-reach stability and fully customizable routing configurations.
Custom OM4 MTP-16 APC to 8x LC UPC Harness, 16-Fiber, Crossover
Deploy next-generation 400G multimode connectivity with this elite 16-fiber mpo patch cable. Seamlessly splits a single 400GBASE-SR8 transceiver port into eight individual 50G LC duplex connections. Choose our OEM fiber patch cord for custom lengths, flawless end-face geometry, and massive hyperscale data center scalability.
Custom OS2 MTP-16 APC to 8x LC UPC Harness, 16-Fiber, Crossover
Future-proof your infrastructure with this high-density 400G DR8/XDR8 singlemode transition harness. This bespoke mpo to lc cable provides elite-grade end-face geometry for flawless performance. Order wholesale fiber patch cables customized to your exact specifications to ensure rapid deployment across massive hyperscale data centers.
Request Custom Quote
Custom OM4 MTP-8 to 4x LC UPC Harness, Staggered Breakout Legs
Eliminate cable slack and achieve perfectly neat cabinet routing with our customized staggered mpo breakout cable. Features precision staggered breakout legs tailored to your exact patch panel spacing. Trust our factory for bespoke fiber patch cord configurations that optimize your rack airflow and maintenance.
Custom OM4 MTP-8 to 4x LC UPC Harness, 8-Fiber (Aqua Jacket)
A cost-effective legacy migration harness featuring standard aqua jacketing for easy OM4 identification in mixed-fiber environments. This completely customizable mpo to lc breakout cable is manufactured in-house to guarantee quality. Source your bulk mpo cables direct from Wolontek for unmatched value and tailored lengths.
Custom OS2 MTP-8 APC to 4x LC UPC Harness, Heavy-Duty Black Jacket
Engineered for demanding inter-cabinet connections requiring superior tensile strength, this custom-length harness features a robust black jacket. Use this heavy-duty singlemode mpo fiber cable for ultimate reliability. We manufacture rugged fiber patch cables to meet the exact mechanical specifications of your industrial or telecom projects.
Custom OS2 MTP-8 APC to 4x MDC UPC Harness, Next-Gen High Density
Achieve 3x the density of standard LC patching with this cutting-edge MTP to MDC harness. Employs Very Small Form Factor (VSFF) MDC connectors for the ultimate space-saving solution. This fully customizable mpo breakout is the perfect fiber optic patch cord for future-proofing your high-capacity spine-and-leaf networks.
MTP/MPO to MTP Conversion Cables (Base-8/12/24)
High-Performance MPO Conversion & Fanout Solutions Optimize your 400G/800G network architecture with Wolontek’s precision-engineered conversion cables. We specialize in complex configurations such as 8×3 to 12×2 conversion MPO fanout cables and 24×1 to 12×2 conversion setups, designed to ensure 100% fiber utilization in Base-8 and Base-12 environments. As a direct factory, we provide bespoke lengths and polarity types to eliminate Dark Fibers and maximize your data center efficiency.
💡 Factory Direct Customization: Need specific lengths, staggered legs, or distinct polarities? All cables are 100% OEM configurable with premium US Conec MTP® or standard MPO connectors. Scroll down to view all bespoke options or contact us directly!
100% 3D Tested & OEM Configurable:
Every assembly passes strict 3D end-face geometry and IL/RL testing.
Custom OM4 MTP-12 to 2x MTP-4 Conversion Cable, 8-Fiber, Type B
Seamlessly migrate your legacy infrastructure with this bespoke OM4 mpo conversion cable. Optimized for high-density 40G/100G parallel optics. Sourced directly from our factory, these mtp to mtp cables feature elite-grade connectors, ultra-low insertion loss, and fully customizable lengths for NVIDIA InfiniBand networks.
Custom OS2 MTP-12 to 2x MTP-4 Conversion Cable, 8-Fiber, Type B
Upgrade your long-reach 100G PSM4 architectures with our singlemode OS2 mpo breakout cable. Manufactured in-house, this mtp conversion harness utilizes G.657.A1 bend-insensitive fiber for tight routing. Enjoy wholesale pricing and tailor the cable lengths to your exact data center blueprint.
Custom OM3 MTP-12 to 2x MTP-4 Conversion Cable, 8-Fiber, Type B
A cost-effective Base-8 migration solution for enterprise data centers. This OM3 mpo to mpo cable splits a single MTP-12 port into two MTP-4 links with zero bit-error rates. As an OEM manufacturer, we provide 100% custom lengths and robust fiber optic cables for reliable backbone connectivity.
Custom OM4 MTP-16 APC to 2x MTP-8 UPC Conversion Cable, 16-Fiber
Engineered specifically for 400G SR8 transceiver splitting, this 16-fiber mpo conversion cable connects next-gen OSFP/QSFP-DD ports directly to 200G/100G equipment. Rely on our factory-direct fiber patch cables for precision geometric end-faces, low loss, and 100% bespoke length configurations.
Custom OM4 MTP-16 to 2x MTP-8 APC Conversion Cable, 16-Fiber, Crossover
Eliminate external conversion cassettes in your 400G multimode deployments with our dedicated crossover mtp to mtp cable. Designed for direct switch-to-switch connectivity. Order these premium mpo trunk cables directly from Wolontek to get custom lengths perfectly tailored to your rack architecture.
Custom OS2 MTP-16 to 2x MTP-8 APC Conversion Cable, 16-Fiber, Crossover
Provide a direct backbone-to-spine link with this singlemode 16-fiber mpo conversion harness. Optimized for 400G DR4/XDR4 applications. We manufacture these rugged mpo fiber cables with custom lengths and robust LSZH/OFNP flame-retardant jacketing to meet your most demanding project specifications.
Custom OM4 MTP-24 to 2x MTP-12 UPC Conversion Cable, 24-Fiber, Type A
Ideal for migrating from legacy 10G setups to 100G/120G architectures without replacing backbone cabling. This OM4 mpo breakout cable splits a high-density 24-fiber trunk into two 12-fiber interfaces. Source your mpo cables from our factory for bespoke lengths and Type A/B/C polarity options.
Custom OS2 MTP-24 to 2x MTP-12 APC Conversion Cable, 24-Fiber, Type A
Maximize 100% fiber utilization when patching Base-24 backbone trunks into standard Base-12 singlemode transceivers. This high-capacity OS2 mtp conversion cable is 3D interferometer tested. Trust Wolontek for OEM-grade fiber optic patch cables delivered in fully customizable lengths to match your layout.
Custom OM4 MTP-24 to 3x MTP-8 UPC Conversion Cable, 24-Fiber, Type B
The ultimate Base-8 migration tool. Converts a single 24-fiber port into three 8-fiber channels, perfectly matching 40G QSFP+ SR4 transceiver requirements. We provide this mpo conversion cable in fully bespoke lengths, ensuring zero wasted dark fibers in your data center.
Custom OS2 MTP-24 to 3x MTP-8 APC Conversion Cable, 24-Fiber, Type B
Designed for singlemode PSM4 deployments. This custom-length mtp to mtp cable distributes a 24-core backbone into three 8-core connections, heavily reducing cabinet congestion. Buy direct from our factory to optimize your airflow with premium fiber optic cables.
Custom OM4 2x MTP-12 to 3x MTP-8 UPC Conversion Cable, 24-Fiber, Type B
Advanced Y-cable conversion module. Aggregates two standard MTP-12 links and seamlessly repatches them into three MTP-8 ports. This highly customized mpo breakout harness fully optimizes your existing Base-12 infrastructure for Base-8 hardware with custom tailored lengths.
Custom MTP/MPO to MTP Breakout Cable Assembly, OEM/ODM Design
Can’t find your exact network configuration? As a direct source factory, we build fully customized Base-8/12/16/24 conversion harnesses. Specify your fiber mode, jacket material, and precise staggered leg lengths for a tailored backbone solution.
Comprehensive MTP® Breakout Specifications
Swipe/scroll horizontally to compare our full range of configurations. Wolontek provides 100% 3D interferometer testing and optional 0.10dB Elite Grade insertion loss across all assemblies.
| Specification |
8-Fiber MTP to LC (OM4)
|
8-Fiber MTP to LC (OS2)
|
16-Fiber MTP to LC (OM4)
|
16-Fiber MTP to LC (OS2)
|
MTP-12 to 2x MTP-4 (OM3)
|
MTP-12 to 2x MTP-4 (OM4)
|
MTP-12 to 2x MTP-4 (OS2)
|
|---|---|---|---|---|---|---|---|
| Fiber Mode | OM4 50/125μm | OS2 9/125μm | OM4 50/125μm | OS2 9/125μm | OM3 50/125μm | OM4 50/125μm | OS2 9/125μm |
| Wavelength | 850/1300nm | 1310/1550nm | 850/1300nm | 1310/1550nm | 850/1300nm | 850/1300nm | 1310/1550nm |
| Connector A | MTP®-8 UPC (F) | MTP®-8 APC (F) | MTP®-16 APC (F) | MTP®-16 APC (F) | MTP®-12 APC (F) | MTP®-12 APC (F) | MTP®-12 APC (F) |
| Connector B | 4x LC UPC Duplex | 4x LC UPC Duplex | 8x LC UPC Duplex | 8x LC UPC Duplex | 2x MTP®-4 APC (F) | 2x MTP®-4 APC (F) | 2x MTP®-4 APC (F) |
| Glass Fiber | Bend Insensitive | G.657.A1 | Bend Insensitive | G.657.A1 | Bend Insensitive | Bend Insensitive | G.657.A1 |
| Bend Radius (Optical) |
7.5mm | 10mm | 7.5mm | 10mm | 7.5mm | 7.5mm | 10mm |
| Bend Radius (Dynamic/Static) |
20D / 10D | 10D / 5D | 20D / 10D | 10D / 5D | 20D / 10D | 20D / 10D | 10D / 5D |
| Insertion Loss (Elite Grade) |
MTP ≤ 0.10dB LC ≤ 0.15dB |
MTP ≤ 0.10dB LC ≤ 0.15dB |
MTP ≤ 0.10dB LC ≤ 0.15dB |
MTP ≤ 0.10dB LC ≤ 0.15dB |
MTP ≤ 0.10dB All Connectors |
MTP ≤ 0.10dB All Connectors |
MTP ≤ 0.10dB All Connectors |
| Return Loss | MTP ≥ 20dB LC ≥ 30dB |
MTP ≥ 60dB LC ≥ 50dB |
MTP ≥ 20dB LC ≥ 30dB |
MTP ≥ 60dB LC ≥ 50dB |
≥ 45dB | ≥ 45dB | ≥ 60dB |
| Attenuation | ≤2.3dB/km at 850nm ≤0.6dB/km at 1300nm |
≤0.35dB/km at 1310nm ≤0.21dB/km at 1550nm |
≤2.3dB/km at 850nm ≤0.6dB/km at 1300nm |
≤0.35dB/km at 1310nm ≤0.21dB/km at 1550nm |
≤2.3dB/km at 850nm ≤0.6dB/km at 1300nm |
≤2.3dB/km at 850nm ≤0.6dB/km at 1300nm |
≤0.35dB/km at 1310nm ≤0.21dB/km at 1550nm |
Your Trusted Global Fiber Partner
Inside Our MPO/MTP Manufacturing
100% rigorous testing and robust production capacity to secure your supply chain.
45,000+
MPO/MTP Connectors
Daily Production Capacity6000+
Optical Transceivers
Daily Production Capacity100%
3D Interferometer Tested
Strict End-Face Geometry Control400+
Skilled Production Staff
Across 3 Automated Factories
Ready to Leverage Our Manufacturing Scale?
Partner with WolonFiber for your next large-scale deployment. Get custom OEM/ODM solutions, aggressive factory-direct pricing, and 72-hour rapid prototyping.
See Our Quality in Action
Go behind the scenes and watch the complete manufacturing and testing process of our ultra-high-density 192-Fiber MTP patch cords below.
WolonFiber: Direct MPO/MTP Breakout Cable Manufacturer & OEM Factory
Seamlessly bridge the gap between high-density backbone infrastructures and active network ports. From our advanced Wuhan Optical Valley facility, we engineer premium custom MTP/MPO to LC, SC, or MDC fanout and breakout assemblies. Designed for 40G-to-10G, 100G-to-25G, and advanced 400G/800G transceiver port-splitting layouts, we turn complex multi-fiber routing into flawless, low-loss physical connectivity.
Advanced Quality Control
100% 3D interferometer verification on the MTP/MPO base connector paired with meticulous ferrule concentricity tracking on every split LC/SC connector channel. We provide complete batch IL/RL metrics to eliminate signal distortion during multi-port transceiver migration.
OEM Design Agility
Tailored branching setups for ultra-dense network environments. Fully customize precise fanout leg diameters (0.9mm micro-tubes, 2.0mm ruggedized legs), customized staggered leg profiles to prevent patch panel clutter, protective furcation kits, and modern space-saving MDC or SN micro-interfaces.
Private Labeling
Comprehensive layout tracing helpers including clear colored fanout leg buffering, durable fiber channel numbering clips (1-12 / 1-24 routing indicators), and custom wrapping tags to streamline active line card site installations.
Your Path to Custom MTP/MPO Breakout Solutions
Consultation
Port splitting logic blueprint mapping, stagger profile engineering, and single-fiber connector compatibility checks.
Prototyping
Rapid mechanical fanout kit mockups and precise branch clearance evaluation within target high-density encloures.
Mass Production
High-volume fiber breakout grouping using industrial heat-shrink matrix reinforcements and automated geometric end-face screening.
Global Logistics
Tangle-proof sequence loop bundling, individual breakout branch anti-crush sleeve wrapping, and global express air transit.
100% Customizable MTP/MPO Breakout Cables Solutions
Tailor every detail to your data center port-replication architecture. WolonFiber offers end-to-end OEM/ODM assembly from micro-fanout rapid prototyping to bulk hardware production.
Need a Bespoke Breakout Layout?
Submit your target active hardware port blueprints to our engineering team today for direct factory pricing and rapid global shipment.
Contact Us TodayBuying Guide: Choosing the Right MTP®/MPO Breakout Solution
Scaling your enterprise data center to 100G, 400G, or 800G compute architectures requires absolute port precision. Whether you are splitting a high-speed spine switch breakout port down to multiple distributed leaf line cards, or feeding high-density signals directly into server NICs, selecting the right pre-terminated fiber breakout cable matrix is critical for protecting your link loss budget.
1. MTP® vs. MPO: The Difference
While often used interchangeably across deployment orders, MTP® is a registered trademark of US Conec representing mechanical enhancements. A custom MTP breakout cable features redesigned floating ferrules and elliptical guide pins to ensure superior physical fiber face contact and lower channel insertion loss compared to a standard unbranded MPO breakout cable.
2. MTP to LC Fanout Cables
The quintessential hardware migration link. An MTP to LC breakout cable splits a single aggregated QSFP/OSFP multi-fiber port into multiple independent 10G/25G/100G LC duplex connections for server NIC arrays, substantially optimizing 1U panel rack packing density and clean fiber tracing.
3. MTP to MTP Conversion
Not all high-density breakout tails terminate in LC single fiber ends. An MTP to MTP fiber breakout array (such as 1x 24-fiber converting to 3x 8-fiber tails) allows operators to aggregate three separate 40G QSFP+ channels back into a single 120G CXP active cluster port, achieving 100% full core utilization across modern Base-8 infrastructure.
4. Base-8 vs. Base-12 Architecture
Modern high-speed 400G transceivers (such as QSFP-DD DR4) operate strictly on 8-fiber lanes. Utilizing a native Base-8 MPO to LC breakout cable ensures zero dark or wasted internal fibers, unlike legacy Base-12 links where 4 cores remain unused. WolonFiber factory specializes in exact engineering across Base-8, 12, and 24 configurations.
5. Jacket Ratings: LSZH vs OFNP
Building fire safety compliance is an absolute mandate. We extrude our custom fiber breakout cables with distinct flame-retardant composites. Specify premium OFNP (Plenum) for standard forced-airflow pathways across North America, or low-smoke halogen-free LSZH configurations for corporate European facilities.
6. Polarity & Elite Grade Loss
Standard parallel splitting configurations typically run on Type B (Reversed) polarity standards. As a direct-source OEM manufacturing factory, WolonFiber guarantees 100% multi-stage geometric interferometer screening. We strongly suggest specifying our Elite Grade (0.35dB max MTP, 0.1dB LC IL) MTP patch cables to prevent bit-error rates across compute nodes.
Frequently Asked Questions
Find quick, technical answers about our high-density MTP/MPO breakout and fanout cabling solutions.
Yes. As a direct OEM manufacturer, our MPO and breakout cables are rigorously tested to meet MSA standards. We guarantee 100% compatibility with all mainstream equipment providers, including Cisco, Arista, Juniper, Mellanox (NVIDIA), HPE, Dell EMC, Brocade, Huawei, and Fortinet.
Most 40G to 10G or 100G to 25G applications require Type B (Reversed) polarity to ensure the Tx-to-Rx link is correctly mapped. If you are unsure about your network architecture, our engineers can provide a free wiring diagram verification to secure your routing layout.
Elite Grade connectors utilize superior ferrules to achieve a maximum insertion loss of 0.35dB (typical 0.10dB). This is absolutely critical for tight-budgeted 400G and 800G networks where the optical loss headroom is extremely small.
Yes. As a direct factory, WolonFiber offers custom staggered fanouts for neat, effortless patching in high-density panels, or equal-length legs for general routing. We can fully customize the breakout length from 0.3m to 2m+ based on your specific cabinet and chassis layout.
Absolutely. Every batch of our MPO/MTP breakout assemblies undergoes 100% 3D geometry testing to strictly monitor apex offset, fiber height, and radius of curvature. Individual test reports can be supplied along with your delivery to guarantee zero-defect performance.
Because we control the entire OEM manufacturing process inside our Hubei factories, our turnaround is exceptionally rapid. Standard custom fanout configurations typically ship within 3 to 7 business days, bypassing the multi-week delays common with trading distributors.
